New ride!!! 2011 Escape Upfit

OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
my new mode 2...


and my mode 1...


OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
well i can RMA these but im trying to figure out if they are sending 12 diode apollos or fusions...

OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
RMA sent after talking with tech support. trying to figure out if they will send F12s or fusions..

OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
Teaser pic. vids to follow after I get day time vids...


I like them alot...

OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
Well pending a local installer looking at these Friday to double check what I already know I decided to do these pics real quick...
This is my cobra "takedowns" and the 2 fusions on steady white...

Looking at them from the neighbors house you see lit up


Close up to get all 4 lights in frame..

OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
Hmm guess I never updated but after RMA on that pair of fusions i got another pair and they worked flawlessly...

Project for last weekend...

Out with appolo with suctions





In with new fusion with window mount

Also added a dashcam a few weeks back...


Waiting on pucks now.. and to hit the lottery so I can get a 4200, hammer, pushbar, feed the hogs, wash the laundry,.finish up.my home work....

OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
been awhile since i have done anything major... but here we go...

Finally got an APRS tracker... Byonics RTG it's a 10 watt transmitter and one of their tiny track 3s in a self contained box...


It takes a small GPS, uses it's signal turns it into a packet and send it's through the airwaves .. which is picked up and retransmitted by DigiPeter's and Igates...

So here's some install pics...

Last edited:
OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
All of the pics loaded out of order..

here it is all installed and running. db9 connectors are the GPS. antenna and power/ ground...



Attaching the anderson power pole connector to the ground side.. this wasnt attached yet just adding the connector to a roll of ground wire.




I didnt "label" the 2 wires i added to the console so i used a good ole HF meter to see which wire had power when the switch was on..

no flash to see the unit powers on and works...



pulling the wires through the carpeting to the rear to the storgae box...



running the wires under the carpet tot he console..





HF meter again for the 2nd wire






wires up in the console before attaching to the Carling console switches.







wires fed through to the rear... while i had this opened back up i put some loom on the side mounted fusion.. in this pic is 2 coax cables the GPS cable (db9 lead) wiring for the fusion and the 2 new power wires..



used the trailer wire negative for the negative post for the HF meter.. LOL





The snake under the carpet now..




The GPS unit. it is supposed to go on the roof. but since it doesnt come in a NMO mount and i didnt want it up on the roof i checked with the maker and he said as long as there isnt too much metal between it and the outside world it should work here... its up on a "hump" near the back glass. i test ran it for a few days there and it never moved with its magnets so it should be good there...




had to drill a big hole for the db9 to pass through pre connection.. you can see the antenna coax here as well. i bought a small SMA to pl259 cable to run from the RTG to the antenna



connection of power wires before looming



Attachments

Last edited:
OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
this is the 2 switches (from a few pages back in case you didnt want to go back and look.)

obviously i hooked the APRS up to he custom switch LOL and the the 2nd wire will be going to yup, you guessed... (but when) I am debating if i want to surface mount some leds into the bumper or do one of those trailer hitch mount bars... (similar to this but not as big of lights https://www.amazon.com/dp/B01CUROPSI/?tag=elightbars-20 )






1st time it got picked up by a digipeter/ igate... on my way to work today my county is a deadspot for APRS but thats another project for another day that im only a few components away from.. the closest digi /igates are in Rutherford, Coffee, and Maury counties..





When i went to lunch in the town with the digi / igate


Last edited:
OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
Another project done for now. Im not to crazy of this set up but its temporary. I still want to flush mount some leds in the bumber but this will work for now.



this is an IDMjoy mount that is readily available on many sites. I paid about $30 shipped for it it is "supposed" to fit on most receiver hitches.






i always upload these in order but they get flipped somehow.. this was testing it on the battery...KIMG1348.JPG


mounted and tested on switch power

yes it was somewhat day light when i started, temps in the 90s so i waited a bit for it too cool off some. i had to mount the lights on top of the mount as the brackets dont fit on the bottom this bracket is meant for stud mount lights but i didnt want the big ol things hanging down from the bottom as they would bottom out every time i left the house....

i also had to disassemble one lens to make it when the spots where on the inside and floods on the outside... also had to flip it so the light was closer to the mount and not 2 inches taller as shown.. the lights are from wally world and were $22 a piece.



distance shot about 25 feet away




testing the wiring before shrinkwrapping everything.. used a couple of SAE plugs to make for quick disconnects. (as seen in photo above)



back of the mount to show height differences





test fit before wiring (note flood spot spot flood configuration)





the switch





remeber the red wire with a cap from last update.. ohh look there it is....

there isnt really a place to mount a ground on the hitch. since i had a ground here for the 4 pin relay, and the wiring from the cannon come through here.. i ran the power wire through the same hole as the ground as the cannon and grounded it in the same spot as the relay ground.






lights on i beleive this is when i put the 2 pin sae plug on the trailer connector to test wiring before i hooked up switch power.




light wiring butt spliced/ heat shrink individual wires and then added a bigger piece of heat shrink to cover both. also zip tied the 2 light wires for protection




i beleive this picture speaks for itself.. next slide please...






ran the wiring from the lights under the bumper between the hitch the SAE plug is about another 6 inches behind that i still need to loom tot he plug...




i guess i didnt add a pic of the other end of the wiring. but i have about 4 feet of wiring running from behind tail light to the other plug. in case i get bored with this or need to take it for some reason , i can just reach back unplug it and its off...

Last edited:
OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
back up camera with new lights on





back up cam without new lights on..... i upgraded the backup lights with leds (https://www.superbrightleds.com/moreinfo/miniature-and-subminiature-bulbs/194-led-bulb-cob-led-t325-miniature-wedge-base-135-lumens/6325/14245/?utm_source=product_review_email&utm_medium=email&utm_campaign=product_review_email) as well but they arent as bright as id like so im still looking for better options...

most of the light you are seeing is from the LP lights i upgraded them to led 194s back when i first got the vehicle..



so i still have room for 2 more devices in that console plate.
1 will be a front led bar if i can find a pushbar with one already built in and the other IDk for now.. LOL

Last edited:

Sparky_911

Member
Gold Supporter
Keep looking around on SBL...I've bought a lot of bulbs from them and sometimes the cheaper versions are better than the higher lumen versions.

OP
OP
Jarred J.

Jarred J.

Archive Expert
Silver Supporter
Fanfare music...

Antennas are now permanent and no longer 4 mag mounts...

The antennas after I took the mags off and rolled up the coax. With the NMOs still curled up.


I didn't want to take pics of the Installer without his permission so I didn't get in progress pics..


Yes they are closer together then I wanted but with little space comes little possibilities... We put the first antenna where the sun roof tracks stopped... And the last antenna just before the real dome light..

The 2 primary transmitter antennas are more than 1/4 wave apart so in theory they are safe...

The other 2 is the scanner and 220mhz and won't be affected by the other 2 so they are spaced 7 inches apart...

So there's another project off my list.

I will post another up date I did a few weeks back later..

Looking at bull bars now so that's next as well...
